TT Size
Color
Regular price €419,99
/
  • Secure payments
  • Low stock - 1 item left
  • Backordered, shipping soon
Tax included. Shipping calculated at checkout.

The Envy XLT frame is a lightweight high-performance take on a modern-day frame, the envy has been carefully lightened up in all non-critical areas to remove more than 650g. Designed to shred it on all-terrain, the Envy XLT utilizes the very best material and manufacturing methods to make an absolutely bombproof frame, which weighs much less than you’d think… includes a lifetime guarantee.

Material: Butted Japanese seamless 4130 crmo tubing

Colour: Anthracite

Features:

  • 74mm mid size bottom bracket CNC machined and heat-treated
  • 120mm CNC machined and heat-treated headtube w/ integ. H/set
  • Drilled for gyro tabs
  • 6mm investment cast dropouts heat-treated 4130 crmo
  • Pivot-3 removable brake mounts (frame comes without repl. Brake hardware)
  • Technical modern frame designed with reducing weight whilst retaining high strength
  • Hydroformed top and down tube for superior strength and stiffness
  • Larger 1.8mm welding at head tube
  • Wider rear triangle allows clearance for a 2.4" tire
  • Ovalized chain stays for increased tire & sprocket clearance
  • Cnc seat stay bridge
  • Tapered and butted tubing to reduce weight
  • 6mm seat clamp bolt
  • Includes lifetime guarantee

Geometry:

  • Top tube length: 20.5"
  • 20.75"
  • 21" or 21.25"
  • Chain stay length: 12.55" – 13.35" - optimized for 12.75" w/25-9
  • Head tube angle: 75.25°
  • Seat tube angle: 71.5°
  • Bb height: 11.7"
  • Standover height: 8.75"

Weight: 4.8lbs / 2.11kg
