Color
Regular price €999,99
/
  • Secure payments
  • In stock, ready to ship
  • Inventory on the way
Tax included. Shipping calculated at checkout.

Designed and developed in Cologne, Germany over a two-year period, the Solar is manufactured from the highest quality Torayca carbon and is incredibly unique with its 100% monocoque 1pc construction. By using a mono-construction compared to a 2/3pc construction which most other brands use, we were able to make the frame even stiffer and stronger and create no weak or fatigue points.

The Solar frame is laboratory tested and proven to be insanely stiff and lightweight especially under high impact and stress tests. The internal cable routing allows for a super clean and stealthy setup. Tested by the Raceline team the past x2 seasons and now the frame of choice for many of today’s top riders, we could not be prouder of what we have created with the Solar frame.

Material high-performance TORAYCA carbon fiber

Top Tube Length (actual) 21.75” (553mm)

Top Tube Length (effective) 22.9” (584mm)

Chainstay Length (min.) 14.5” (368mm)

Dropout Size 15mm

Head Tube Angle 74.5°

Seat Tube Angle 71°

Head Tube Size (full int.) tapered 1-1/8” – 1.5” (120mm)

Seat Post Size 27.2mm

Seat Tube Length 238mm

Bottom Bracket Type Euro, threaded, BSA 68mm

Bottom Bracket Height 11.6″ (EU)

Wheel Size 20″ x 1.75″

Rider Area 540.7mm

Extras Inc. • full monocoque technology

• internal cable routing

• laboratory tested for superior strength and
stiffness

Weight 1.210kg/2.66lbs
